5 Ton Top Running Motorized End Trucks Single Girder up to 34ft Span 220/440V 3P
SKU: PWNT-5T-HSE160-15 Solicitar

Características Esenciales

  • For heavy-duty class “C” single girder crane applications
  • Drives and brakes are compatible with Variable Frequency Drive (VFD)
  • Suitable for use on ASCE crane rail or square bar
  • 3 Años de Garantía, Servicio y Atención al Cliente en Mexico
Artboard 1
For heavy-duty class “C” single girder crane applications, Top running motorized end trucks. Include 2 trucks; 2 gear motors with D.C. brakes, rubber bumpers. All trucks are fully painted. Runway Rail ASCE # 40

Especificaciones Técnicas

PWNT-5T-HSE160-15
  • Capacidad de Carga 5 Ton
  • Velocidad /min 66 ft
  • Numero de Velocidades 1 Speed - Optional Variable Speed
  • Voltaje 3 Phase 220~240/440~480V 60Hz
  • Potencia Total Watts 0.37 x 2
  • Luz Maxima 30 Ft
  • Material Steel
  • Clase de Servicio H4/M5/2m/Class D
  • Freno Motor Yes
  • Protección IEC Motor IP54
  • Variador de Frequencia Optional 1.1 Kw
  • Freno Dinámico Only with VFD Optional
  • Control Not Included. Optional single Speed, 2 Speed and Variable Speed
  • Rango de ancho de la Viga Any
  • Normas ASME / CMAA / Nch
  • Garantía 3 Year

Peso & Dimensiones

  • Largo de testera 1500 mm
